SPECIFICATION
Connections in the base of instrument
Communications: Type RS-232C
Baud 38400 Max. ASYNC
External power supply: Input voltage DC 7.2 to 11V
Battery pack BC-65
Output voltage: DC 7.2V, rechargeable
Continuous operation time: About 16hours
(For angle/distance measurements at 25°C
of normal temperature)
(Note that this operation time differs
depending on the deterioration of battery.)
Environmental performance
Operating temperature range: –20°C to +50°C/–4°F to +122°F
Storage temperature range: –25°C to +60°C/–13°F to +140°F
Dimensions
Main unit: 168 (W) x 173 (D) x 335 (H)mm
Carrying case: 435 x 280 x 218mm
Weight
Main unit: Approx. 4.7kg/10.36lbs.
Battery BC-65: Approx. 0.4kg/0.88lbs.
Quick charger Q-75U/E: 0.45kg/0.99lbs.
Carrying case: Approx. 2.5kg/5.51lbs.
