Measuring Distances
1) Sighting a prism reflector
WARNING
Never view the sun through the
telescope.
Doing so may cause loss of eyesight.
Sight the telescope crosshairs on the center of
the prism reflector. When reflected light is
detected, the signal level is indicated.
For assembling the prism reflector, refer to p.2-11.
Sighting a single prism
Sighting a tiltable single prism
MSR
1 ○
A
B
C
TRK
3 ○
G
H
I
