Nikon DTM-330 - Simple Station Input (XYZ-Key); Xyz

3-29
3
XYZ
Simple Station input (XYZ-key)
The [XYZ] key is a simple and conventional way of setup.
1) Input the station coordinate
2) Set the horizontal angle by [ANG] key
※No ST record is stored to the DB in this function.
Therefore, when you try to record data to an open job after using this key,
your SS/CP records follow a comment record (CO, STN is changed
by [XYZ] key) instead of ST.
Input Height of Target, Height of
Instrument, XYZ coordinate of the
Station.
The Horizontal angle input is optional. If
you reset the angle by [ANG] key or you
don’t have to change the angle, you can
just press [ENT].
*
／
＝
XYZ
0 ○
ＨＴ： １．３５６ ｍ
ＨＩ： １．６４６ ｍ
Ｘ： ３８６４．９９０
Ｙ： －１８７２．５０７
1
Ｘ： ３８６４．９９０
Ｙ： －１８７２．５０７
Ｚ： ４２．１８５
ＨＡ：
1
This function can be used without an open job. It is useful when you
need to continue surveying despite the “Data Full” environment, for
example, you can use this [XYZ] + [ANG] setup as an emergency
means on site.
