Nikon DTM-330 - 3-2) Angle-Offset Measurements

3-68
3
REC/Offset
3-2) Angle-Offset Measurements
After a distance measurement, press the
[REC] and [2:O/S] to show the Offset
menu screen.
Select [2] key to enter the angle-offset.
The current reading of HA/VA is shown.
You can rotate the alidade and telescope to
take a necessary angle offset with the
measured distance kept unchanged.
Press the [ENT] or [4:OK] to record the
offset point.
The XYZ data will also be recalculated
based on the new angle.
１：Ｔａｐｅ ５：Ｃｎｒ
２：Ａｎｇｌｅ ６：＋ＳＤ
３：Ｐｏｌｅ ７：Ｃｉｒｃｌ
４：＋Ｌｉｎｅ
２
Ａｎｇｌｅ Ｏｆｆｓｅｔ
ＨＡ：２３４°３２′１４″
ＶＡ： ９１°５５′０９″
Ａｂｒｔ ＯＫ
－ ＲＥＣ ＲＡＷ －
Ｊｏｂ：ＴＯＫＹＯ１２
The [2:O/S] key is not available for angle shots and F1/F2 shots.
In those cases, the O/S softkey will be left blank.
