Nikon DTM-330 - Standard Components

5-4
5
SPECIFICATION
5-2 Standard Components
DTM-350/330 main body: 1
Battery pack BC-65: 1
Quick charger Q-75U or Q-75E: 1
Tool set: 1
Objective lens cap: 1
Vinyl cover: 1
Instruction manual: 1
Carrying case: 1
Shoulder strap: 1
5-3 External Device Connection Connector
This connector is used commonly as a power source connector and a
communication connector with an external device.
Confirm the specifications below and observe the cautions on the next page.
Input voltage: DC7.2 – 11V
System: RS-232C, Asynchronous
Signal level: ±9V Standard
Rate: 38400bps Max.
Compatible male connector: Hirose HR10A-7P-6P or
Hirose HR10-7P-6P
Hirose HR 10A-7R-6S
 RxD: Reception data (Input)
 TxD: Send data (Output)
 +
 –
, : No connection






