NSD VARILIMIT VS-12PB User Manual

● 4-2 ●
4-1-3. Input/Output Signal Specifications
(1) Control Input/Output Signal Specifications
Input Signals Output Signals
Item
Specification
Item
Specification
Number of input points
10 points
Item
19 points
Isolation format
Photo-coupler
Number of output points
Photo-coupler
Rated input voltage 24 VDC
Isolation format 24 VDC
Rated input current
10 mA Rated load voltage
20.4 to 30 VDC
Input voltage range used
20.4 to 30 VDC
Load voltage range used
100 mA
ON voltage 12 VDC or more
Max. Load current
0.4 A
OFF voltage
4 VDC or less
Current leakage when OFF
0.1 mA or less
Max. Voltage drop when ON
0.5 VDC (at 100 mA)
Response
time(µs)
OFF → ON
40 (with input voltage of 24 V)
Response
time(µs)
OFF → ON
40 (when load current is 100 mA)
ON → OFF
200 (with input voltage of 24 V)
ON → OFF
200 (when load current is 100 mA)
External cable connection format
Plug type terminal board F5014-38P
(2) BCD Input / Output Signal Specifications
Input
Signals
Output Signals
Item Specification
Item
Specification
Number of input points
BCD inputs: 24 points
Symbol inputs: 1 point
DTC inputs: 1 point
Number of output points
BCD outputs: 24 points
Symbol outputs: 1 point
latch pulse outputs: 1 point
Isolation format Photo-coupler Isolation format Photo-coupler
Rated input voltage
24 VDC
Rated load voltage 24 VDC
Rated input current
10 mA
Load voltage range used
20.4 to 30 VDC
Input voltage range used
20.4 to 30 VDC Max. Load current 100 mA
ON voltage
12 VDC or more
Max. Rush current
0.4 A
OFF voltage
4 VDC or less Current leakage when OFF 0.1 mA or less
Max. Voltage drop when ON
0.5 VDC (at 100 mA)
Response
time(µs)
OFF → ON
40(with input voltage of 24 V)
Response
time(µs)
OFF → ON
40(when load current is 100 mA)
ON → OFF
200(with input voltage of 24 V)
ON → OFF
200(when load current is 100 mA)
External cable connection format
Connector MR-34RMA
