9-15
9-4-3. Other Parameter Settings
The following parameter settings should be designated only when the function is being used.
The factory setting values (default values) are shown in box. Unless another setting is desired, there setting items can be skipped.
Parameter
No.
Item Description Setting data
Setting
Value
44
Medium-speed zone
When the speed-stepping format is used, this
setting designates the medium-speed zone for
the positioning operation.
Setting range:
[0999999]
10000
49
Motion non-detection
timer
Designates the time period from the point when
positioning is started, until the point when motion
error monitoring begins.
Note
If a setting of 0 is designated, the motion
nondetection timer function will be inoperative.
Setting range:
[0.0099.99s]
10.00
50
Motion mis-direction
non-detection timer
Designates the time period from the point when
positioning is started, until the point when
direction error monitoring begins.
Note
If a setting of 0is designated, the motion
misdirection non-detection timer function will be
inoperative.
Setting range:
[0.0099.99s]
10.00
51
Positioning END
detection timer
Designates the delay time period from the point
when the operation output switches OFF, until
the point when the RUN signal switches OFF.
Setting range:
[0.00
99.99s]
0.10
52
INCHING zone
Add the INCHING zone to the target stop
positon when using the INCH function.
Designates this adding INCHING zone.
Setting range:
[-99999
999999]
100
53
INCHING ON time
Designates the INCHING ON time during
Inching operation.
Setting range:
[1
9999ms]
100
54
INCHING OFF time
Designates the INCHING OFF time during
Inching operation.
Setting range:
[1
9999ms]
100
55
INCHING In-Position
zone
Designates the INCHING In-position zone which
serves as the criterion for determining whether
positioning has stopped at the target stop
position.
Setting range:
[0
999999]
100
61
Upper limit
Designates the plus direction limit.
Setting range:
[-99999
999999]
999999
62
Lower limit
Designates the minus direction limit.
Setting range:
[-99999
999999]
-99999
63
STOP zone max.
value
Designates the Learning functions maximum
STOP zone correction value.
Setting range:
[0
999999]
999999
64
STOP zone min. value
Designates the Learning functions minimum
STOP zone correction value.
Setting range:
[0
999999]
0
65
Permissible current
pos. change amount
The ABSOCODER sensor checks the amount
of change in the current position every 20 ms.
This setting designates the maximum amount of
change which is to be permissible.
Setting range:
[0
999999]
999999
66
Permissible correction
amount
Designates the maximum current position
correction which is to be permitted during current
position PRE operations.
Setting range:
[0
999999]
999999
