9-3-2-5. Minimum current position value (Initial No.94)
Designates the minimum current position value which will be displayed.
Note
Setting range: -99999 to 1000000 - Scale length
[1] Setting the minimum current position value. (Ex.: -10)
Designates the setting value using numeric key as
desired.
[2] Enter the data setting.
Press the key twice
Note
The key must be pressed twice to set the data.
The above setting enables position detection through a “-1000 (-10.00) to 126999 (1269.99)” range.
The system will automatically proceed to Initial No.95.
Note
Initial No.93 and No.94 setting items must be
designated as a pair in order to be valid.
