9-17
9-5. RUN
RUN operations for the VS-12PB are described below.
RUN operations consist of normal operations and trial run operations (TEST mode).
In the TEST mode, the following 3 operations can be performed, and the limit switch outputs can be checked.
Positioning
Limit switch output
AUTO positioning
Limit switch output
INCHING
JOG
The 4 main operation keys (located on the control panel) are shown below.
Test RUN operations are executed in the TEST mode.
During Test Run operations, all external inputs except the RESET, PRE1, and PRE2 inputs are inoperative.
(However, the SEL input is operative during INCHING operations.)
The VS-12PB RUN operations consist of positioning control and limit switch outputs.
External Input Signals
Control Outputs
OPE1 OPE2
AUTO positioning
OFF
ON
INCHING
ON
ON
JOG
ON
OFF
Each operation is selected by the external input signals.
For detail regarding Limit switch output, refer to 9-6 Limit switch output setting.
Note
Numerical inputs can be performed by keying in the values directly from the ten-key pad, or by using the
teaching function (current position input). In this manual, teaching inputs are indicated by an apostrophe
mark ( ) following the procedure step number (e.g. [4]).
