NSD Varlimit VS-212DN User Manual

9-3
Error Type
Error
code
Description
When
Detected
Countermeasure
Control
errors
42
VS-212DN detected a 'motion error' (no motion) during an 'operation
output' ON.
- During positioning.
-
During online
JOG operation.
- Check the 'operation output'
connections.
- Check the motor control unit.
- Revise the 'motion non-detection timer'
setting.
43
VS-212DN detected a 'motion direction error' (motion in opposite
direction) during an 'operation output' ON.
- Check the 'operation output'
connections.
- Check the motor.
- Revise the 'motion misdirection non-
detection timer' setting.
50
A 'current position preset' was attempted to a point outside the
detection range.
During a 'current
position preset'
operation.
- Revise the 'current position
preset' value.
- Revise the scale length and
minimum current position
value.
Data
errors
60 VS-212DN detected a parameter setting error.
- When power is
turned ON.
- When program
switching occurs.
- When positioning
START occurs.
Correct the parameter setting.
61
VS-212DN detected a program No. 1 setting error.
When power
is turned ON,
and when
switching to
the program
in question.
Re-designate the setting data.
62
VS-212DN detected a program No. 2 setting error.
63
VS-212DN detected a program No. 3 setting error.
64
VS-212DN detected a program No. 4 setting error.
65
VS-212DN detected a program No. 5 setting error.
66
VS-212DN detected a program No. 6 setting error.
67
VS-212DN detected a program No. 7 setting error.
68
VS-212DN detected a program No. 8 setting error.
69 VS-212DN detected a current position setting error.
When power
is turned ON.
Re-designate the current position
setting data.
70 Data writing error occurred.
When data writing
is executed. Re-designate the setting.
Buffer
memory
data errors
110
Activated when
incorrect data is
written to the buffer
memory.
Speed limit area
When positioning
START occurs.
Correct the sequence program
to prevent incorrect data from
being written to the buffer
memory.
112
Medium-speed zone area
113
Low-speed zone area
114
FWD stop zone area
115
RVS stop zone area
116
In-position zone area
117
Current position preset input 1 area
During preset
status
118
Current position preset input 2 area
130
Sequence mode selection area
During
parameter
data loading
at sequence
mode
190
Sensor rotation direction area
191
Decimal point position area
192
Scale length area
193
Minimum current position value area
194
Current position setting area
150
Function area
151
Positioning format area
152
Positioning direction area
153
Overshoot amount area
154
Medium-speed zone area
155
Low-speed zone area
156
Stop zone area
157
In-position zone area
