2.6 ABSOCODER Sensor
(1) Multi-turn type ABSOCODER sensor:
o Multi-turn type MRE
Item
Specifications
Model
MRE-
□
32SP062
G64SP062
G128SP062
G160SP062
G256SP062
G320SP062
Number of turns
32
64
128
160
256
320
Divisions/Turn
4096
2048
1024
819.2
512
409.6
Mass (kg)
1.5
1
Moment of inertia (kg
・
m
2
)
6.7
×
10
-6
3.9
×
10
-6
Starting torque (N
・
m)
4.9
×
10
-2
or less
Permissible shaft
load (N)
Radial
98
Thrust
49
Permissible mechanical speed(r/min)
3600
Bearing Life (at 3600r/min)
3
×
10
4
Hr
1.5
×
10
4
Hr
Ambient
temperature
Operating (
℃
)
-20 to +60
Storage (
℃
)
-30 to +90
Vibration resistance
2.0
×
10
2
m/s
2
, 200Hz , up/down 4h, forward/back 2h,
conforms to JIS D1601 standard
Shock resistance
4.9
×
10
3
m/s
2
, 0.5ms , up/down/forward/back
×
3 times each,
conforms to JIS C5026 standard
Protection rating
IP52f conforms to JEM 1030 standard
Max. cable
Length (m)
Standard cable: 4P-S
100
Robotic cable: 4P-RBT
40
70
IMPORTANT
An ABSOCODER sensor should be selected which has a ABSOCODER detection range (distance
over which absolute position detection is possible) which exceeds the machine’s travel amount.
ABSOCODER sensor’s detection range
Machine travel range
2.7 Extension Cable Specifications
Item Specifications
Model
4P-S-□ 4P-RBT-□
Cable type Standard cable Robotic cable
Operating temperature range
－5 to ＋60℃
Characteristics Extensible for long distance Superior flexibility; ideal for moving components
Insulator Irradiated, formed polyethylene ETFE plastic (resin)
Sheath Polyvinyl chloride (PVC) mixture
Color
Gray
Black
