11. CE MARKING
VARILIMIT “VS-212DN” conforms to EMC directive.
11.1 EMC Directives
It is necessary to do CE marking in the customer’s responsibility in the state of a final product.
Confirm EMC compliance of the machine and the entire device by customer because EMC changes
configuration of the control panel, wiring, and layout.
11.2 EMC Directive and Standards
EMC consists of emission and immunity items.
It conforms to Table (see below) of EMC standards and Testing.
Emission (EMI) EN61000-6-4
Generic standards.
Emission standard for industrial environments
Immunity (EMS)
EN61000-6-2
Generic standards.
Immunity standard for industrial environments
Radiated, Radio frequency, Electromagnetic Field
Electrical Fast Transient / Burst
Conducted Disturbances, Induced by Radio-Frequency Fields
Power Frequency Magnetic Field
11.3 Low Voltage Directive
The low voltage directive is out of the range because VS-212DN is activated by 24VDC power supply.
11.4 Restrictions
(1) Install the zippertubing around the cable when sensor cable is used 30m or more. The shield of
zippertubing should be grounded.
Recommendation Zippertubing
φ
ZIPPERTUBING(JAPAN), LTD.
(2) The I / O cable must be under 30m from the host controller to the converter. The wiring should be
surely secured.
[Reference]
It may be improved when clamp ferrite core is added to the Power supply, DeviceNet, I/O, 1axis
senser and 2axis senser cables when it operates faultily by the influence from the peripheral device.
Recommendation Clamp Ferrite Core (Product name: Clamp filters for cable)
ZCAT2032-0930 (Inner dimensions: 9mm)
ZCAT2032-0930 (Inner dimensions: 9mm)
ZCAT3035-1330 (Inner dimensions: 13mm)
ZCAT2032-0930 (Inner dimensions: 9mm)
ZCAT2032-0930 (Inner dimensions: 9mm)
