Wiring and Connections Section 3-4
Expansion I/O Unit with 20 I/O Points: CPM2C-20EDR
Note Terminals 12 and 13 are internally connected. The maximum common capac-
ity is the same as for other common circuits.
Expansion I/O Unit with 8 Output Points: CPM2C-8ER
Output capacity Max. common capacity
2 A (250 VAC or 24 VDC) 4 A/common
Outputs: IR word n
Load
Load
Load
Load
Load
Load
Load
Load
Output capacity Max. common capacity
2 A (250 VAC/24 VDC) 4 A/common
COM
01@02
01@01
COM
01@03
COM
01@00
01@04
01@05
01@06
01@07
COM
COM
COM
7
6
5
4
3
2
1
1
2
3
4
5
6
7
Outputs: IR word n
Load
Load
Load
Load
Load
Load
Load
Load
