DM Settings Assignment Sheets Appendix C
Read Data Area (SYSWAY: Temperature Controllers)
Read Data Area (SYSWAY: Digital Panel Meters)
DM _____ Contents Data Command group
12345
DM (+0) Response monitor area Read Read Read Read Read
DM (+1) Present temperature Read Read Read Read Read
DM (+2) Status Read Read Read Read Read
DM (+3) Target temperature Read Read Read Read Read
DM (+4) Alarm 1 SV --- --- Read Read Read
DM (+5) Alarm 2 SV --- --- Read Read Read
DM (+6) Proportional band --- --- --- Read Read
DM (+7) Reset time --- --- --- Read Read
DM (+8) Derivative time --- --- --- Read Read
DM (+9) Heater current monitor --- --- --- --- Read
DM (+10) Heater current status --- --- --- --- Read
DM _____ Contents Data Command group
12345
DM (+0) Response monitor area Read Read Read Read Read
DM (+1) Display value (Lower bytes) Read Read Read Read Read
DM (+2) Display value (Upper bytes) Read Read Read Read Read
DM (+3) Display value status Read Read Read --- Read
DM (+4) Peak hold (Lower bytes) --- Read Read --- Read
DM (+5) Peak hold (Upper bytes) --- Read Read --- Read
DM (+6) Peak hold status --- Read Read --- Read
DM (+7) Bottom hold (Lower bytes) --- Read Read --- Read
DM (+8) Bottom hold (Upper bytes) --- Read Read --- Read
DM (+9) Bottom hold status --- Read Read --- Read
DM (+10) Comparison value HH (Lower bytes) --- --- --- Read Read
DM (+11) Comparison value HH (Upper bytes) --- --- --- Read Read
DM (+12) Comparison value H (Lower bytes) --- --- --- Read Read
DM (+13) Comparison value H (Upper bytes) --- --- --- Read Read
DM (+14) Comparison value L (Lower bytes) --- --- --- Read Read
DM (+15) Comparison value L (Upper bytes) --- --- --- Read Read
DM (+16) Comparison value LL (Lower bytes) --- --- --- Read Read
DM (+17) Comparison value LL (Upper bytes) --- --- --- Read Read
