288
DM Settings Assignment Sheets Appendix C
Write Data Area (SYSWAY: Temperature Controllers)
Write Data Area (SYSWAY: Digital Panel Meters)
DM _____ Contents Data Command group
12345
DM (+0) Response monitor area Written Written Written Written Written
DM (+1) Target temperature SV Written Written Written Written Written
DM (+2) Operation Command --- Written Written Written Written
DM (+3) Alarm 1 SV --- --- Written Written Written
DM (+4) Alarm 2 SV --- --- Written Written Written
DM (+5) Proportional band --- --- --- Written Written
DM (+6) Reset time --- --- --- Written Written
DM (+7) Derivative time --- --- --- Written Written
DM (+8) Heater burnout detection value --- --- --- --- Written
DM _____ Contents Data Command group
12345
DM (+0) Response monitor area Written Written Written Written Written
DM (+1) Operation Command --- --- Written --- Written
DM (+2) Comparison value HH (Lower bytes) --- --- --- Written Written
DM (+3) Comparison value HH (Upper bytes) --- --- ---
DM (+4) Comparison value H (Lower bytes) --- --- --- Written Written
DM (+5) Comparison value H (Upper bytes) --- --- ---
DM (+6) Comparison value L (Lower bytes) --- --- --- Written Written
DM (+7) Comparison value L (Upper bytes) --- --- ---
DM (+8) Comparison value LL (Lower bytes) --- --- --- Written Written
DM (+9) Comparison value LL (Upper bytes) --- --- ---
