Other Functions (TC4 and TC2) Section 4-7
4-7-2 Event Inputs (TC2)
Event Input
Assignment
There are two event inputs in the TC2.
The following diagram shows the parameters that can be set in event input 1
or event input 2.
Some of the parameters are for all channels and others are for individual
channels.
Note This parameter can be set only when operation is stopped.
When this parameter has been changed, the new setting becomes effective
the next time a software reset is performed for the Unit or the next time power
is turned ON.
Controlling Operation with
the Event Input’s ON/OFF
Status
• Operation can be switched by OFF-to-ON or ON-to-OFF event-input tran-
sitions.
■ Stop (0)/Run (1), Run (0)/Stop (1), Auto (0)/Manual (1), Local SP (0)/
Remote SP (1)
Note This function can be used only when the Remote SP Enable parameter is set
to 1 (Enable).
Variable type Parameter name Setting range Default
F2/B2 Event Input 1 or 2 Assignment
(Common)
0 to 69 0
Conditions for use No special conditions
EV2 can be set in the same way.
EV2
Settable
parameters
EV1
Channel 2
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
Disabled
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
All channels
Run (0)/Stop (1)
Channel 1
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
ON
OFF
Parameter Event input Description
Stop (0)/Run (1) OFF Stop
ON Run
Run (0)/Stop (1) OFF Run
ON Stop
Auto (0)/Manual (1) OFF Auto
ON Manual
Local SP (0)/Remote SP (1) (See note.) OFF Local SP
ON Remote SP
