Unit Configuration Examples Section 2-4
2-4 Unit Configuration Examples
Minimal Configuration • The two auxiliary alarm outputs (transistor outputs) provided on the End
Unit can be used.
• The G3ZA can be connected.
Multiple Units without an
HFU
• The two auxiliary alarm outputs (transistor outputs) provided on the End
Unit can be used.
• G3ZA outputs can be used.
• Distributed placement is possible by using multiple End Units.
Port A (connector): USB connection
can be made using the E58-CIFQ1
(sold separately).
EJ1@-TC4
or
EJ1@-TC2
EJ1@-EDU
CX-Thermo for
setting
Computer
G3ZAG3ZA G3ZA
PLC PT
EJ1@-TC4
or
EJ1@-TC2
EJ1@-EDU
Port A (connector): USB connection
can be made using the E58-CIFQ1
(sold separately).
Computer
CX-Thermo for setting
Computer
Port B: RS-485 (CompoWay/F)
