Control Linked to a Host Device Section 3-3
3-3-3 Setup
TC4 Refer to 3-2 Multi-channel Control for details on the EJ1@-TC4 settings.
HFU The settings are made through communications. The EST2-2C-MV3 CX-
Thermo Support Software can be connected using an E58-CIFQ1 Connecting
Cable to set the parameters from a personal computer.
• The following table shows the parameters related to communications
between the EJ1 and PLC, as well as example settings. Set the unit num-
ber of the HFU to 0.
Parameter Set value Remarks
Initial setting level
Port C Communications Baud Rate 115.2 (kbps) Default
Port C Communications Data Length (See note 1.) 8 (bit) Default
Port C Communications Parity (See note 1.) Even Default
Port C Communications Stop Bits (See note 1.) 1 (bit) Default
Port C Send Wait Time (See note 1.) 5 (ms) Default
Programless
Common settings
Programless Communications Protocol NT Link (1:N) Default
Programless Communications Upload Data Area (See note 1.) DM Default
Programless Communications Download Data Area (See note 1.) DM Default
Programless Communications Upload Start Address (See note 1.) 0 Default
Programless Communications Download Start Address (See note 1.) 500 Default
Programless Communications Receive Wait Time (See note 1.) 200 (ms) Default
Programless Communications Node Address (See note 1.) 0 Default
Upload settings
Programless Upload Settings 4 Unit No. 1 - Common - Device A Status
Programless Upload Settings 5 Unit No. 1 - CH1 - Process Value
Programless Upload Settings 6 Unit No. 1 - CH2 - Process Value
Programless Upload Settings 7 Unit No. 1 - CH3 - Process Value
Programless Upload Settings 8 Unit No. 1 - CH4 - Process Value
Programless Upload Settings 9 Unit No. 2 - Common - Device A Status
Programless Upload Settings 10 Unit No. 2 - CH1 - Process Value
Programless Upload Settings 11 Unit No. 2 - CH2 - Process Value
Programless Upload Settings 12 Unit No. 2 - CH3 - Process Value
Programless Upload Settings 13 Unit No. 2 - CH4 - Process Value
Programless Upload Settings 14 Unit No. 3 - Common - Device A Status
Programless Upload Settings 15 Unit No. 3 - CH1 - Process Value
Programless Upload Settings 16 Unit No. 3 - CH2 - Process Value
Programless Upload Settings 17 Unit No. 3 - CH3 - Process Value
Programless Upload Settings 18 Unit No. 3 - CH4 - Process Value
Programless Upload Settings 19 (See note 2.) Unit No. 0 - Common - End Code
Download settings
Programless Download Settings 4 Unit No. 1 - CH1 - Set Point
Programless Download Settings 5 Unit No. 1 - CH2 - Set Point
Programless Download Settings 6 Unit No. 1 - CH3 - Set Point
Programless Download Settings 7 Unit No. 1 - CH4 - Set Point
Programless Download Settings 8 Unit No. 2 - CH1 - Set Point
Programless Download Settings 9 Unit No. 2 - CH2 - Set Point
Programless Download Settings 10 Unit No. 2 - CH3 - Set Point
Programless Download Settings 11 Unit No. 2 - CH4 - Set Point
Programless Download Settings 12 Unit No. 3 - CH1 - Set Point
Programless Download Settings 13 Unit No. 3 - CH2 - Set Point
Programless Download Settings 14 Unit No. 3 - CH3 - Set Point
Programless Download Settings 15 Unit No. 3 - CH4 - Set Point
Programless Download Settings 16 Unit No. 0 - Common - End Code
