37
Minimum Configuration for Control Section 3-1
3-1-4 Adjustment
Execute autotuning (AT) to make the PID adjustments.
Refer to 4-3-8 Tuning.
When the CX-Thermo Support Software is being used, both EJ1 control and
autotuning can be started/stopped using operation commands.
Special Remarks The CX-Thermo Support Software starts in Beginner Mode by default. When
you want to set parameters that are not displayed in Beginner Mode, select
View - View Mode and switch to Expert Mode to enable the advanced set-
tings.
In addition, the View Mode can be set to normal display or functional group
display. When functional group display is selected, items are grouped by func-
tion rather than displayed separately as they are in the normal display mode.
The functional group display makes it easy to set all of the parameters related
to a function without overlooking any of the required parameters.
