Omron EJ1 User Manual

192
Sensor Input Ranges Appendix
Sensor Input Ranges
• Applicable standards by input type are as follows:
K,J,T,E,N,R,S,B: JIS C1602-1995
L: Fe-CuNi, DIN43710-1985
U: Cu-CuNi, DIN43710-1985
W: W5Re/W26Re, ASTM E988-1990
PLII: According to Platinel II Electromotive Force Table by Engelhard Corp.
JPt100: JIS C1604-1989, JIS C1606-1989
Pt100: JIS C1604-1997, IEC751
Input type Specifica-
tion
Set value Setting range Indication range
°C °F °C °F
Temperature inputs
Platinum
resistance
thermome-
ters
Pt100 0 −200 to 850 −300 to 1500 −220 to 870 −340 to 1540
1 −199.9 to 500.0 −199.9 to 900.0 −219.9 to 520.0 −239.9 to 940.0
2 0.0 to 100.0 0.0 to 210.0 −20.0 to 120.0 −40.0 to 250.0
JPt100 3 −199.9 to 500.0 −199.9 to 900.0 −219.9 to 520.0 −239.9 to 940.0
4 0.0 to 100.0 0.0 to 210.0 −20.0 to 120.0 −40.0 to 250.0
Thermocou-
ple
K5−200 to 1300 −300 to 2300 −220 to 1320 −340 to 2340
6 −20.0 to 500.0 0.0 to 900.0 −40.0 to 520.0 −40.0 to 940.0
J7−100 to 850 −100 to 1500 −120 to 870 −140 to 1540
8 −20.0 to 400.0 0.0 to 750.0 −40.0 to 420.0 −40.0 to 790.0
T9−200 to 400 −300 to 700 −220 to 420 −340 to 740
10 −199.9 to 400.0 −199.9 to 700.0 −219.9 to 420.0 −239.9 to 740.0
E 11 0 to 600 0 to 1100 −20 to 620 −40 to 1140
L12−100 to 850 −100 to 1500 −120 to 870 −140 to 1540
U13−200 to 400 −300 to 700 −220 to 420 −340 to 740
14 −199.9 to 400.0 −199.9 to 700.0 −219.9 to 420.0 −239.9 to 740.0
N15−200 to 1300 −300 to 2300 −220 to 1320 −340 to 2340
R 16 0 to 1700 0 to 3000 −20 to 1720 −40 to 3040
S 17 0 to 1700 0 to 3000 −20 to 1720 −40 to 3040
B 18 100 to 1800 300 to 3200 0 to 1820 0 to 3240
W 19 0 to 2300 0 to 4100 −20 to 2320 −40 to 4140
PLII 20 0 to 1300 0 to 2300 −20 to 1320 −40 to 2340
ES1B
Infrared
Thermosen-
sor
10 to 70°C 21 0 to 90 0 to 190 −20 to 130 −40 to 270
60 to 120°C 22 0 to 120 0 to 240 −20 to 160 −40 to 320
115 to 165°C 23 0 to 165 0 to 320 −20 to 205 −40 to 400
140 to 260°C 24 0 to 260 0 to 500 −20 to 300 −40 to 580
Analog inputs
Current input 4 to 20 mA 25 Any of the following ranges, by scaling:
−1999 to 9999
−199.9 to 999.9
−19.99 to 99.99
−1.999 to 9.999
−5% to 105% of the setting range
0% to 105% for 0 to 20 mA
0 to 20 mA 26
Voltage input 1 to 5 V 27
0 to 5 V 28
0 to 10 V 29
