Omron EJ1 User Manual

158
Detailed Description of Services
Section 6-4
6-4-11 Operation Commands
The following parameter settings are made using operation commands.
■ Command
Service Request PDU
■ Response
Service Response PDU
1. Command Code by Unit and Related Information
• Write Mode • Software Reset • Run • Stop
• Manual • Automatic • AT Execute • AT Cancel
• Bank 0 Change to
Bank 3 Change
• LSP Mode • RSP Mode • Reset Error
• Alarm 1 to Alarm 3 Latch Cancel • All Alarm Latch Cancel
• Save RAM Data • Parameter Initialization • Save RAM Data 2
• Register Unit Configuration
MRC SRC
2
3
2
0
2 2
05
Related
information
Command
code
4
MRC SRC
2
3
2
005
Response
code
Command code TC related information HFU related information TC4 and TC2 HFU
Write Mode 04 00: Backup
01: RAM
Supported Sup-
ported
Software Reset 06 Always 00.
Run 0A 00 to 03: Channel
FF: All channels
--- ---
Stop 0B
Manual 0C
Auto 0D
40% AT Execute 0E
100% AT Execute 0F
AT Cancel 10
Bank 0 Change 1E
Bank 1 Change 1F
Bank 2 Change 20
Bank 3 Change 21
Local SP Change 22
Remote SP Change 23
Reset Error 2D Always 00. --- ---
Alarm 1 Latch Cancel 32 00 to 03: Channel
FF: All channels
Alarm 2 Latch Cancel 33
Alarm 3 Latch Cancel 34
All Alarm Latch Cancel 35
Save RAM Data (See note 1.) 37 Always FF. Always FF. Sup-
ported
Parameter Initialization 38 Always 00.
Save RAM Data 2 (See note 2.) 39 Always FF. Always FF.
Register Unit Configuration 3B 00: Reset
01: Register
---
