48
Controlling G3ZA Controllers Connected to Output Devices Section 3-4
3-4-3 Setup
The settings are made through communications. The EST2-2C-MV3 CX-
Thermo Support Software can be connected using an E58-CIFQ1 Connecting
Cable to set the parameters from a personal computer.
The following table shows the parameters related to the G3ZA that can be set
from the Temperature Controller, as well as example settings.
Note • The Programmable Terminal and E58-CIFQ1 Connecting Cable cannot
be connected at the same time.
• When connecting the cable for the Support Software to an EJ1C-EDU
End Unit, either turn OFF the Programmable Terminal's power supply or
switch the Programmable Terminal's screen to the system menu.
3-4-4 Adjustment
Execute autotuning (AT) to make the PID adjustments.
Refer to 4-3-8 Tuning for details.
Set the slope and offset values independently to match the system. (The
default value for the slope is 100.0% and the default value for the offset is
0.0%.)
Variable type Address Parameter name Set value
DA 0100 G3ZA
Unit number 01
CH1 Slope 0650: 65.0%
0101 CH2 Slope 0648: 64.8%
0102 CH3 Slope 0655: 65.5%
0103 CH4 Slope 0640: 64.0%
0108 CH1 Offset 0050: 5.0%
0109 CH2 Offset 0050: 5.0%
010A CH3 Offset 0050: 5.0%
010B CH4 Offset 0050: 5.0%
0110 CH1 Source Channel 0001: Channel 1
0111 CH2 Source Channel 0001: Channel 1
0112 CH3 Source Channel 0001: Channel 1
0113 CH4 Source Channel 0001: Channel 1
0124 Offset control 0001: Enabled
0200 G3ZA Unit number 02 Same as G3ZA Unit number 01
0300 G3ZA Unit number 03
0400 G3ZA Unit number 04
