40
Multi-channel Control Section 3-2
Note • Connect the PT to port B.
• Set the write mode to backup mode.
• Set the PT's communications parameters the same as the port B commu-
nications parameters.
3-2-4 Adjustment
Execute autotuning (AT) to make the PID adjustments.
Refer to 4-3-8 Tuning for details.
CH3 - Set Point (Variable type D4, Address 0300) 1150: 115. 0°C
CH4 - Set Point (Variable type D4, Address 0400) 1150: 115. 0°C
CH1 - Control Period 1 (Variable type E1, Address 0101) 0000: 0.5 s
CH2 - Control Period 2 (Variable type E1, Address 0201) 0000: 0.5 s
CH3 - Control Period 3 (Variable type E1, Address 0301) 0000: 0.5 s
CH4 - Control Period 4 (Variable type E1, Address 0401) 0000: 0.5 s
Related parameters Description
