51
Setting Input Specifications Section 4-1
4-1 Setting Input Specifications
4-1-1 Input Type
Set the input type to match the type of sensor being used.
Note This parameter can be set only when operation is stopped.
List of Input Types
Variable type Parameter name Setting range Default
E0/A0 Input Type (Channel) 0 to 29 5
Conditions for use No special conditions
Input type Specifica-
tion
Set value Setting range
(°C) (°F)
Tempera-
ture
input
Platinum
resistance
thermom-
eter
Pt100 0 −200 to 850 −300 to 1500
1 −199.9 to 500.0 −199.9 to 900.0
2 0.0 to 100.0 0.0 to 210.0
JPt100 3 −199.9 to 500.0 −199.9 to 900.0
4 0.0 to 100.0 0.0 to 210.0
Thermo-
couple
inputs
K5−200 to 1300 −300 to 2300
6 −20.0 to 500.0 0.0 to 900.0
J7−100 to 850 −100 to 1500
8 −20.0 to 400.0 0.0 to 750.0
T9−200 to 400 −300 to 700
10 −199.9 to 400.0 −199.9 to 700.0
E 11 0 to 600 0 to 1100
L12−100 to 850 −100 to 1500
U13−200 to 400 −300 to 700
14 −199.9 to 400.0 −199.9 to 700.0
N15−200 to 1300 −300 to 2300
R 16 0 to 1700 0 to 3000
S 17 0 to 1700 0 to 3000
B 18 100 to 1800 300 to 3200
W 19 0 to 2300 0 to 4100
PLII 20 0 to 1300 0 to 2300
ES1B
Infrared
Tempera-
ture
Sensor
10 to 70°C 21 0 to 90 0 to 190
60 to 120°C 22 0 to 120 0 to 240
115 to 165°C 23 0 to 165 0 to 320
140 to 260°C 24 0 to 260 0 to 500
Analog
inputs
Current
input
4 to 20 mA 25 Any one of the following ranges,
by scaling:
−1999 to 9999
−199.9 to 999.9
−19.99 to 99.99
−1.999 to 9.999
0 to 20 mA 26
Voltage
input
1 to 5 V 27
0 to 5 V 28
0 to 10 V 29
