Omron EJ1 User Manual

193
Parameter List Appendix
Parameter List
If variables without parentheses are used in communications, the set values will be eight-digit (double-word)
data. If variables with parentheses are used in communications, the set values will be four-digit (word) data.
Example: Variable type C4: Double word (8 digits)
Variable type 84: Word (4 digits)
Note The values in the current bank will be used for all set values.
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
C0 (80) Monitor 0000 Process Value - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0001 Status - CH1 See Status Lists on page 209. --- --- ch ● ---
0002 Internal SP - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
Not used.
0004 MV Monitor (Heating) - CH1 H' FFFFFFFB to H' 00000069 (−5.0 to 105.0) --- % ch ● ---
0005 MV Monitor (Cooling) - CH1 H' FFFFFFFB to H' 00000069 (−5.0 to 105.0) --- % ch ● ---
Not used.
0100 Process Value - CH2 The rest are the same as channel 1.
··· ···
0200 Process Value - CH3
··· ···
0300 Process Value - CH4
··· ···
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
C1 (81)
(See
note.)
Monitor Not used.
0003 Set Point - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0004 Alarm Value 1 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0005 Alarm Upper Limit Value 1 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0006 Alarm Lower Limit Value 1 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0007 Alarm Value 2 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0008 Alarm Upper Limit Value 2 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0009 Alarm Lower Limit Value 2 - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
Not used.
0103 Set Point - CH2 The rest are the same as channel 1.
···
0203 Set Point - CH3
···
0303 Set Point - CH4
···
