Omron EJ1 User Manual

194
Parameter List Appendix
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
C4 (84) Monitor 0000 Device A Status See Status Lists on page 209. --- --- Common ●●
0001 Device Error Status See Status Lists on page 209. --- --- Common ●●
0002 Configuration Error A Status See Status Lists on page 209. --- --- Common ●●
0003 Configuration Error B Status See Status Lists on page 209. --- --- Common ● ---
0004 Internal Communications Error Status See Status Lists on page 209. --- --- Common ● ---
0005 I/O Error Status See Status Lists on page 209. --- --- Common ● ---
0006 I/O Alarm A Status See Status Lists on page 209. --- --- Common ● ---
0007 I/O Alarm B Status See Status Lists on page 209. --- --- Common ● ---
Not used.
0009 I/O Notification A Status See Status Lists on page 209. --- --- Common ● ---
Not used.
000B Error Channel A Status See Status Lists on page 209. --- --- Common ● ---
Not used.
000F Basic Unit/Expand Unit Error See Status Lists on page 209. --- --- Common ● ---
0010 Basic Unit/Expand Unit Alarm See Status Lists on page 209. --- --- Common ● ---
Not used.
0012 Output Status See Status Lists on page 209. --- --- Common ● ---
0013 Device B Status See Status Lists on page 209. --- --- Common ●●
Not used.
0020 Version H' 00000000 to H' 0000FFFF --- --- Common ●●
Not used.
0100 Process Value - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0101 Channel Status - CH1 See Status Lists on page 209. --- --- ch ● ---
0102 Channel Alarm Status - CH1 See Status Lists on page 209. --- --- ch ● ---
0103 Internal SP - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0104 Local SP Monitor - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0105 Remote SP Monitor - CH1 H' FFFFF831 to H' 0000270F (−1999 to 9999) --- EU ch ● ---
0106 Bank No. Monitor - CH1 H' 00000000 to H' 00000003 (0 to 3) --- --- ch ● ---
0107 MV Monitor (Heating) - CH1 H' FFFFFFCE to H' 0000041A (−5.0 to 105.0) --- % ch ● ---
0108 MV Monitor (Cooling) - CH1 H' FFFFFFCE to H' 0000041A (−5.0 to 105.0) --- % ch ● ---
Not used.
010B Decimal Point Monitor - CH1 H' 00000000 to H' 00000003 (0 to 3) --- --- ch ● ---
Not used.
0200 Process Value - CH2 The rest are the same as channel 1.
··· ···
Note: The Remote SP Monitor - CH2 parameter is supported only by the TC4.
0300 Process Value - CH3 Note: The Remote SP Monitor - CH3 parameter cannot be used. TC4 ---
··· ···
0400 Process Value - CH4 Note: The Remote SP Monitor - CH4 parameter cannot be used. TC4 ---
··· ···
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
C5 (85) Monitor 0100 Heater Current Value 1 Monitor H' 00000000 to H' 0000044C (0.0 to 110.0) --- A IO TC2 ---
0101 Leakage Current Value 1 Monitor H' 00000000 to H' 0000044C (0.0 to 110.0) --- A IO TC2 ---
Not used.
0200 Heater Current Value 2 Monitor The rest are the same as Heater Current Value 1 Monitor.
··· ···
