Setting Output Specifications Section 4-2
4-2 Setting Output Specifications
4-2-1 Control Output Assignments
The parameters shown in the following diagram can be assigned to each out-
put by setting the control output assignments.
The same parameter can be assigned to different outputs.
Note Temperature Controller Error
The Temperature Controller Error output will turn ON when an bit
between bit 0 and bit 13 in the Device A Status is ON. It can be
used to output EJ1 error status. Refer to Status Lists on page 209
for details on Device A Status.
Note These parameters can be set only when operation is stopped.
Refer to Parameter List on page 193 for details on the settings.
4-2-2 Control Output Method
The time-proportional output method is used for the control output.
The MV determines the percentage of time that the output is ON during each
control period.
Variable type Parameter name Setting range Default
TC4 TC2
E1/A1 Control Output 1 Assignment (I/O) 0 to 144 47
Control Output 2 Assignment (I/O) 0 to 144 79
Control Output 3 Assignment (I/O) 0 to 144 111 32
Control Output 4 Assignment (I/O) 0 to 144 143 64
Conditions for use No special conditions
Channel 4
Channel 4
Channel 2
• OUT2, OUT3, and OUT4 can be set in the same way.
• Channels 3 and 4 are supported only by the TC4.
Input Error OR
RSP Input Error OR
Alarm 1 to 3 OR
Alarm 1 to 3 AND
HB (Heater Burnout) Alarm OR
HS (Heater Short) Alarm OR
OC (Heater Overcurrent) Alarm OR
All Alarm AND
All Alarm OR
All channels
Disabled
Temperature Controller Error
Settable
parameters
OUT1 OUT2 OUT3 OUT4
HS (SSR Failure) Alarm
Heater Burnout Alarm
RSP Input Error
Input Error
Alarm 1 to 3
OC (Heater Overcurrent) Alarm
Channel 4
All Alarm AND
All Alarm OR
Process Value
Internal SP
Local SP
Remote SP
Control Output (Heating)
Control Output (Cooling)
HS (SSR Failure) Alarm
Heater Burnout Alarm
RSP Input Error
Input Error
Alarm 1 to 3
OC (Heater Overcurrent) Alarm
Channel 3
All Alarm AND
All Alarm OR
Process Value
Internal SP
Local SP
Remote SP
Control Output (Heating)
Control Output (Cooling)
HS (SSR Failure) Alarm
Heater Burnout Alarm
RSP Input Error
Input Error
Alarm 1 to 3
OC (Heater Overcurrent) Alarm
Channel 2
All Alarm AND
All Alarm OR
Process Value
Internal SP
Local SP
Remote SP
Control Output (Heating)
Control Output (Cooling)
HS (Heater Short) Alarm
HB (Heater Burnout) Alarm
RSP Input Error
Input Error
Alarm 1 to 3
OC (Heater Overcurrent) Alarm
Channel 1
All Alarm AND
All Alarm OR
Process Value
Internal SP
Local SP
Remote SP
Control Output (Heating)
Control Output (Cooling)
To Next Page
