Omron EJ1 User Manual

36
Minimum Configuration for Control Section 3-1
4. The following table shows the related parameter settings for this example.
CX-Thermo Beginner Mode Setting Example
Setting example Remarks
EJ1N-TC2A-QNHB 0
--- ---
CH1
Control in progress parameters
Bank 0
Bank 0 Set Point - CH1 150
°C
Bank 0 Proportional Band - CH1 8.0
°C Default
Bank 0 Integral Time - CH1 233 s Default
Bank 0 Derivative Time - CH1 40.0 s Default
Bank 0 Alarm Value 1 - CH1 0
°C
Bank 0 Alarm Upper Limit Value 1 - CH1
0°C Upper limit alarm; not used.
Bank 0 Alarm Lower Limit Value 1 - CH1
0°C Upper limit alarm; not used.
Bank 0 Alarm Value 2 - CH1 0
°C
Bank 0 Alarm Upper Limit Value 2 - CH1
0°C Upper limit alarm; not used.
Bank 0 Alarm Lower Limit Value 2 - CH1
0°C Upper limit alarm; not used.
Adjustment settings
Manual MV - CH1 0.0% Disabled in Auto mode
HB/HS/OC settings 1
--- ---
Heater Burnout 1 Detection 0.0 A HB alarm OFF
Heater Burnout 2 Detection 0.0 A HB alarm OFF
Control stopped parameters
--- ---
Input settings
Input Type - CH1 5: Thermocouple (K)
Temperature Unit - CH1
°C
Output settings
--- ---
Control Period 1 2 OUT1 control period: 2 s
Alarm settings
--- ---
Alarm 1 Type - CH1 2: Upper-limit alarm
Alarm 2 Type - CH1 2: Upper-limit alarm
Operation commands
--- ---
RUN - CH1
STOP - CH1
Manual - CH1
Auto - CH1
100% AT Execute - CH1
AT Cancel - CH1
