Omron EJ1 User Manual

102
Other Functions (TC4 and TC2) Section 4-7
■ Bus Input Assignments (TC4/TC2)
■ Bus Output Assignments (TC4/C2)
Note Temperature Controller Error
The Temperature Controller Error output will turn ON when an bit
between bit 0 and bit 13 in the Device A Status is ON. It can be
used to output EJ1 error status. Refer to Status Lists on page 209
for details on Device A Status.
• Bus inputs 2 and 3 can be set in the same way.
• Channels 3 and 4 are supported only by the TC4.
Bus input 1 Bus input 2 Bus input 3
Settable
parameters
Channel 4
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
Channel 3
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
Disabled
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
All channels
Run (0)/Stop (1)
Channel 2
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
Channel 1
Stop (0)/Run (1)
Bank (bit 1)
Local SP (0)/Remote SP (1)
Auto (0)/Manual (1)
Bank (bit 0)
Run (0)/Stop (1)
Variable type Parameter name Setting range Default
F2/B2 Bus Input 1 to 3 Assignment
(Common)
TC4: 0 to 132
TC2: 0 to 69
0
Bus Output 1 to 3 Assignment
(Common)
TC4: 0 to 150
TC2: 0 to 87
0
Conditions for use No special conditions
Settable
parameters
Local SP (0)/Remote SP (1)
Alarm 1 to 3
All Alarm OR
All Alarm AND
Heater Burnout Alarm
HS Alarm
OC Alarm
Channel 4
Input Error
RSP Input Error
Bank (bit 0)
Bank (bit 1)
Stop (0)/Run (1)
Run (0)/Stop (1)
Auto (0)/Manual (1)
Local SP (0)/Remote SP (1)
Alarm 1 to 3
All Alarm OR
All Alarm AND
Heater Burnout Alarm
HS Alarm
OC Alarm
Channel 3
Input Error
RSP Input Error
Bank (bit 0)
Bank (bit 1)
Stop (0)/Run (1)
Run (0)/Stop (1)
Auto (0)/Manual (1)
Local SP (0)/Remote SP (1)
Alarm 1 to 3
All Alarm OR
All Alarm AND
Heater Burnout Alarm
HS Alarm
OC Alarm
Channel 2
Input Error
RSP Input Error
Bank (bit 0)
Bank (bit 1)
Stop (0)/Run (1)
Run (0)/Stop (1)
Auto (0)/Manual (1)
Local SP (0)/Remote SP (1)
Alarm 1 to 3
All Alarm OR
All Alarm AND
HB (Heater Burnout) Alarm
HS (Heater Short) Alarm
OC (Heater Overcurrent) Alarm
Channel 1
Input Error
RSP Input Error
Bank (bit 0)
Bank (bit 1)
Stop (0)/Run (1)
Run (0)/Stop (1)
Auto (0)/Manual (1)
HB (Heater Burnout) Alarm OR
HS (Heater Short) Alarm OR
OC (Heater Overcurrent) Alarm OR
Input Error OR
RSP Input Error OR
Temperature Controller Error
All Alarm OR
All Alarm AND
Alarm 1 to 3 OR
Alarm 1 to 3 AND
All channels
Disabled
Event Input 1 to 4
Bus Input 1 to 3
Bus input 1 Bus input 2 Bus input 3
• Bus inputs 2 and 3 can be set in the same way.
• Channels 3 and 4 are supported only by the TC4.
