Programless Communications Section 5-1
• Refer to the following table and set a start address within the accessible
range.
Note (1) Make sure the same address is not allocated in both the Programless Up-
load Settings and Programless Download Settings.
(2) Reset the EJ1 to enable settings.
Communications
Settings
The following parameters are used to make the EJ1 communications settings.
Set these parameters to the same conditions as the PLC.
Note Reset the EJ1 to enable settings.
When using an NT Link, use the default settings.
Adjusting
Communications
Time with PLC
With programless communications, the time from when the command is sent
to the PLC until a response is returned is monitored using the Programless
Communications Receive Wait Time.
• This time will differ, depending on the PLC cycle time. Consider the PLC
system configuration and allow sufficient margin when setting the
response wait time. Communications will not be normal if this setting is
too short.
Note Reset the EJ1 to enable settings.
This parameter is not valid when an NT Link is being used.
Programless
Communications
Protocol
PLC area Setting
range
Default
Programless
Communications
Upload Start
Address
Programless
Communications
Download Start
Address
NT Link (1:N) DM 0000 to 9999 0 500
EM
MC protocol
(format 5)
Data registers 0000 to 9999
Link registers 0000 to 1FFF
File registers 0000 to 9999
Variable type Parameter name Setting/Monitor
values
Default
F0/B0 Port C Communications Baud Rate
(Common)
3: 9.6 kbps
4: 19.2 kbps
5: 38.4 kbps
6: 57.6 kbps
7: 115.2 kbps
7
Port C Communications Data Length
(Common)
0: 7 bits
1: 8 bits
1
Port C Communications Parity
(Common)
0: None
1: Even
2: Odd
1
Port C Communications Stop Bits
(Common)
0: 1 bit
1: 2 bits
0
Port C Send Wait Time (Common) 1 to 99 ms 5
Conditions for use No special conditions
Variable type Parameter name Setting range Default
F0/B0 Programless Communications
Receive Wait Time (Common)
10 to
10000 ms
2000
Conditions for use The Programless Communications Protocol must be set to MC
protocol (format 5).
