196
Parameter List Appendix
Note The decimal point position is determined by the sensor selection. With analog inputs, the decimal point
position is determined by the Decimal Point Position parameter setting. In this case, however, the 0 (****)
decimal point position setting will be treated as a setting of 1 (***.*).
Variable
type
Category Add-
ress
Parameter name Setting (monitor) range Defau-
lt
Unit Attribut-
es
Target Unit
TC4/
TC2
HFU
D0 (90) Can be
changed
during
operation.
0100 Bank 0 Set Point - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0101 Bank 0 Proportional Band - CH1 H' 00000001 to H' 0000270F (1 to 9999) 80 EU (See
note.)
BANK ---
0102 Bank 0 Integral Time - CH1 H' 00000000 to H' 00000F9F (0 to 3999) 233 Seconds BANK ---
0103 Bank 0 Derivative Time - CH1 H' 00000000 to H' 0000270F (0.0 to 999.9) 40.0 Seconds BANK ---
0104 Bank 0 SP Ramp Rise Value - CH1 H' 00000000 to H' 0000270F (0 to 9999)
(Function stops when set to 0.)
0 EU/s or
EU/min
BANK ---
0105 Bank 0 SP Ramp Fall Value - CH1 H' 00000000 to H' 0000270F (0 to 9999)
(Function stops when set to 0.)
0 EU/s or
EU/min
BANK ---
Not used.
0107 Bank 0 Manual Reset Value - CH1 H' 00000000 to H' 000003E8 (0.0 to 100.0) 50.0 % BANK ---
0108 Bank 0 Cooling Coefficient - CH1 H' 00000001 to H' 0000270F (0.01 to 99.99) 1.00 --- BANK ---
0109 Bank 0 Dead Band - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU (See
note.)
BANK ---
Not used.
010D Bank 0 Alarm Value 1 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
010E Bank 0 Alarm Upper Limit Value 1 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
010F Bank 0 Alarm Lower Limit Value 1 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0110 Bank 0 Alarm Value 2 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0111 Bank 0 Alarm Upper Limit Value 2 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0112 Bank 0 Alarm Lower Limit Value 2 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0113 Bank 0 Alarm Value 3 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0114 Bank 0 Alarm Upper Limit Value 3 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
0115 Bank 0 Alarm Lower Limit Value 3 - CH1 H' FFFFF831 to H' 0000270F (1999 to 9999) 0 EU BANK ---
Not used.
0200 Bank 0 Set Point - CH2 The rest are the same as channel 1.
···
···
0300 Bank 0 Set Point - CH3 TC4 ---
···
···
0400 Bank 0 Set Point - CH4 TC4 ---
···
···
