Omron F3SJ Series User Manual

126
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
Dimensions

When Using Standard Mounting Brackets
 Backside Mounting
The adjustment angle of F39-LJ3 is from -10deg to +10deg.
Bracket mounting procedure (Mounting) p.152
Top/bottom mounting bracket
Intermediate mounting bracket
)/-
)/-
3.75
6.25E
13.75
B A
30
D
22
31
20
5.5
30
16.5
22
42
2-M5
4-M5
24
30043
1
26
46
E
B
13.75
10
37
42
53
5.5
7
dia. 15
dia. 6
dia. 9
dia. 6.5
2-Top/bottom mounting brackets
2-Mounting holes
2-Mounting holes
M12 Waterproof connector
C (Protective height)
Intermediate mounting
bracket
2-Mounting holes
4-Mounting holes
Beam
(Unit: mm)
20

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
