Omron F3SJ Series - When Using Optional Mounting Brackets

129
F3SJ-A
User’s Manual
Chapter4 Dimensions
Wiring/Installation
E
 When Using Optional Mounting Brackets
 F39-LJ2 Side-mounting Optional Bracket
Dimensions A to C
AC + 74
B C + 39.5
C 4-digit number of the model name (protective height)
F39-LJ2
Use standard brackets
20
275.5
25.5
2
19
37
17.25
B
(17.25)
A B
4-M5
0.39.7
20
35
44
37.6
5
35
C (Protective height)
Material: Stainless steel
(Unit: mm)
dia. 6.5
dia.9
