Omron F3SJ Series User Manual

148
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
 Mounting a Protect Bar
 External Dimensions of Protect Bar F39-PJ-S
Dimensions A to C Dimension D
Protective height Number of used protection brackets (3) D *1
A C+74 245 to 1000 0 -
B C+46.5 1001 to 2000 1 B/2
C 4-digit number of the model
name (protective height)
2009 to 2500 2 B/3
*1 D is for reference and must be a length that should not affect intermediate mounting bracket
16.5
5.5
(37)
1
(13.75)
(13.75)
AB
D
69
64
15
(6)
20
43
23
10
20
3024
dia.9
16
8
dia.6.5
(37)
B
M5
39
D
6.25
20
2-M8
2-M6
3.75
3.75
6.25
B
M5
39
D
20
4-M5
20
C(Protective
height)
dia.5.5
(6)
Hole size for mounting
Protection Bracket (2)
Protection
Bracket (3)
Protection
Bracket (1)
Mounting hole
Backside mounting
(Unit: mm)
Using M5 Using M6 and M8
3-M5
Hex. Bolt
with Washer and Hole
Sensor
4-Mounting holes
2-Mounting holes
2-Mounting holes
4-M3
Hex. Bolt
with Washer
and Hole
Protection Support
Material: Stainless steel and aluminum

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
