F3SJ-A
User’s Manual
Chapter3 Other
What can be done by the setting tool
E
Other
Safety Distance Calculation Function
Overview
The safety distance specified by the international standard ISO13855-2002 (European standard
EN999) is calculated.
Functional Description
This function displays the safety distance based on the international standard ISO13855-2002
(European standard EN999), according to the conditions that are input. This function is available only
for the PC tool for F3SJ.
Monitor Items
Connection Cable Length Calculation Function
Overview
This function displays the connection cable's extendable length, which varies according to the F3SJ
configuration.
Functional Description
The function displays the extendable length of the cable (excluding the length of cables between series
connections), according to the conditions that are input. For series connections, the maximum
extendable length is 15 meters. This function is available only for the PC tool for F3SJ.
Monitor Items
Power Cable Length p.22
Rated Response Time Check
Overview
The rated response time of the F3SJ is displayed.
Functional Description
This function displays the OFF response time (from ON to OFF) and the ON response time (from OFF
to ON) by connecting the F3SJ whose response time you want to check. If the F3SJ are in a series
connection, the response time for all F3SJ connected in series is shown.
Function Setting Console PC Tool For F3SJ
Safety distance calculation function –
Function Setting Console PC Tool For F3SJ
Connection cable extension calculation function –
