Omron F3SJ Series User Manual

26
Chapter2 How to Select a System
F3SJ-A
User’s Manual
System Configuration and Functions
How to Select a System

Selection Flow Chart
Required system configuration depends on functions to be used. Use the following flow chart to
determine the system.
 Combination of Functions
Availability of functional combination is shown below. Other functions than these functions can be
combined.
O: Combination available
: Can be combined by using the PC tool for F3SJ to change the setting. (Cannot be combined by
using the setting console. For details, see Chapter 3. Setting Zone Adjacent Conditions, p.91.)
x: Combination unavailable
Fixed Blanking
Function
Floating Blanking
Function
Muting/Override
Function
Warning Zone
Function
Fixed Blanking Function - O
Floating Blanking Function -
Muting/Override Function O -
Warning Zone Function -
Using muting function
Basic system + Functional setting
change by the setting tool
Using fixed blanking
Using floating blanking
Changing operating range
Using/changing other function
Using fixed blanking
Using floating blanking
Changing operating range
Using/changing other function
Basic system
Muting system + Functional setting
change by the setting tool *1
Muting system *1
NO NO
NO
YES
YES
YES
*1 Key cap for muting (F39-CN6) is required.

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
