99
F3SJ-A
User’s Manual
Chapter3 Indicator/Input & Output Setting
What can be done by the setting tool
E
• External Indicator 2 (Emitter Side)
*1
For a muting system, muting override output is set.
*2
For a muting system, it is configured as disabled.
*3
For a muting system, it is configured as blinking [1.0s].
 Output Operation Mode
See Chapter 3 Auxiliary Output (Non-Safety Output) p.94 Output Operation Mode.
Output Operation Mode p.95
 Interlock Function
 Overview
Start and restart interlock functions can be configured.
Install the interlock reset switch in a location that provides a clear view of the entire haz-
ardous zone and where it cannot be activated from within the hazardous zone.
 Example
•To operate a machine after power-on and inspection
•To restart a machine after safety check when F3SJ was blocked and the machine stopped
 Functional Description
• Interlock Function
Chapter 2 Interlock Function p.29
• Start Interlock
With this setting, F3SJ enters interlock only when power is turned ON. Applying reset input can release
interlock state when no interrupting object exists in the detection zone. This can be used to operate a
machine after power-on and inspection.
• Restart Interlock
With this setting, F3SJ enters interlock state only when the sensor is interrupted. Applying reset input
can release interlock state when no interrupting object exists in the detection zone. If F3SJ is blocked,
the machine can be restarted after safety is ensured.
• Interlock Reset
For basic system: Open or apply voltage of 0 to 1.5V for 250ms or longer to the reset input line, and set
it open or apply 9 to Vs (nominal 24V).
For muting system: Apply voltage of 9 to Vs (nominal 24V) for 450ms or longer to the reset input line,
and apply 0 to 1.5V again.
Function Initial Setting Available Setup Item Setting Console
PC Tool For
F3SJ
Output Operation Mode Lockout
Information *1
See Output Operation Mode

Reverse Output Mode Disabled *2 Enable/disable 
Lighting-Up Pattern ON *3 On/Blink[0.5s]/Blink[1.0s]/Blink[2.0s] 
External Indicator Output
Diagnosis Function
Disabled Enable/disable


Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
