Chapter3 Indicator/Input & Output Setting
What can be done by the setting tool
E
Setting Change
• Auxiliary Output 1
Configure in a bulk in case of a series connection. (to be written into the primary sensor only)
• Auxiliary Output 2
If F3SJ is used for a muting system, auxiliary output 2 cannot be used because it is used as muting input 2.
Muting System Wiring Diagrams p.40
Output Operation Mode (when assigned to auxiliary output and external indicator
output)
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Output Operation Mode Safety Output
Information
See Output Operation Mode
Reverse Output Mode Enabled Enable/disable
Lighting-Up Pattern ON On/Blink[0.5s]/Blink[1.0s]/
Blink[2.0s]
Auxiliary Output
Diagnosis Function
Disabled Enable/disable
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Output Operation Mode Power-On Time
Information
(30,000 hours)
See table below
Reverse Output Mode Disabled Enable/disable
Output Operation Mode
Operational Description
(Output turns ON under following condition)
Setting
Console
PC Tool Forpc
tool for F3SJ
Safety Output Information When safety output is ON
Light Level Diagnosis Information *
1
When F3SJ is under ON state and light intensity is within a
range from 100 to 130% of ON-threshold for 10 seconds or
longer.
Error/Lockout Information Under error/lockout state
Muting/Override Information Under either muting or override state
Blanking/Warning Zone Information *
2
When fixed blanking/floating blanking functions and warning
zone function are enabled
Designated Beam Output Information *
3
When designated beam is interrupted –
Power-On Time Information When power-on time exceeds power-on time threshold
Warning Zone Information *
4
When a warning zone is interrupted
Test input ON information When test input is turned ON
Blanking Beam Incidence Information *
5
When fixed blanking or floating blanking beams are incident
Interlock Information Under interlock state
Muting Error Information Under muting error state
Excess Load Switch Frequency
Information
When the load switching frequency exceeds its threshold.
Information Trigger Information Under either interlock, lockout, or muting error –
Connected Sensor Individual Output
(1CH)
When safety output of 1CH under series connection is ON (auxiliary
output 1 only)
(auxiliary
output 1 only)
Connected Sensor Individual Output
(2CH)
When safety output of 2CH under series connection is ON (auxiliary
output 1 only)
(auxiliary
output 1 only)
Connected Sensor Individual Output
(3CH)
When safety output of 3CH under series connection is ON (auxiliary
output 1 only)
(auxiliary
output 1 only)
Connected Sensor Individual
Output(4CH)
When safety output of 4CH under series connection is ON (auxiliary
output 1 only)
(auxiliary
output 1 only)
