Omron F3SJ Series User Manual

150
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
 Mounting an Environment-Resistant Case
 External Dimensions of Environment-Resistant Case F39-EJ
Dimensions A to D
A C+108
BC+76
C 4-digit number of the model name (protective height)
DC+44
13.5
5.5
20
32
dia.6.5
16
16
2
8
dia. 9
dia. 60.5
AB
D
32
22
8
2
2-M8
2-M6
20
20
8
2
4-M5
BB
Backside mounting
Hole size for mounting
(Unit: mm)
Using M5 Using M6 and M8
Material: Acrylic resin, nitrile rubber, stainless steel
2-Mounting brackets
(F39-EJ-R) *1
C
(Protective
height)
*1 Mounting Bracket (F39-EJ-R) is not included.

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
