Omron F3SJ Series User Manual

17
F3SJ-A
User’s Manual
Chapter1 Ratings
Overview and Specifications
E
 Model Name List/Response Times
F3SJ-A
N14
F3SJ-A
N20
F3SJ-A
N25
F3SJ-A
N30
F3SJ-A
N55
Number of
beams
Response
time
(ON to OFF)
Response
time
(OFF to ON)
- - - - F3SJ-A0270N55 6 beams 10ms 40ms
- - - - F3SJ-A0320N55 7 beams 10ms 40ms
- - - - F3SJ-A0370N55 8 beams 10ms 40ms
- - - - F3SJ-A0420N55 9 beams 10ms 40ms
- - - F3SJ-A0245N30 F3SJ-A0470N55 10 beams 10ms 40ms
- - - F3SJ-A0270N30 F3SJ-A0520N55 11 beams 10ms 40ms
- - - F3SJ-A0295N30 F3SJ-A0570N55 12 beams 10ms 40ms
- - F3SJ-A0260N25 F3SJ-A0320N30 F3SJ-A0620N55 13 beams 10ms 40ms
- - F3SJ-A0280N25 F3SJ-A0345N30 F3SJ-A0670N55 14 beams 10ms 40ms
- - F3SJ-A0300N25 F3SJ-A0370N30 F3SJ-A0720N55 15 beams 10ms 40ms
- F3SJ-A0245N20 F3SJ-A0320N25 F3SJ-A0395N30 F3SJ-A0770N55 16 beams 10ms 40ms
- F3SJ-A0260N20 F3SJ-A0340N25 F3SJ-A0420N30 F3SJ-A0820N55 17 beams 11ms 44ms
- F3SJ-A0275N20 F3SJ-A0360N25 F3SJ-A0445N30 F3SJ-A0870N55 18 beams 11ms 44ms
- F3SJ-A0290N20 F3SJ-A0380N25 F3SJ-A0470N30 F3SJ-A0920N55 19 beams 11ms 44ms
- F3SJ-A0305N20 F3SJ-A0400N25 F3SJ-A0495N30 F3SJ-A0970N55 20 beams 11ms 44ms
- F3SJ-A0320N20 F3SJ-A0420N25 F3SJ-A0520N30 F3SJ-A1020N55 21 beams 11ms 44ms
- F3SJ-A0335N20 F3SJ-A0440N25 F3SJ-A0545N30 F3SJ-A1070N55 22 beams 11ms 44ms
- F3SJ-A0350N20 F3SJ-A0460N25 F3SJ-A0570N30 F3SJ-A1120N55 23 beams 11ms 44ms
- F3SJ-A0365N20 F3SJ-A0480N25 F3SJ-A0595N30 F3SJ-A1170N55 24 beams 11ms 44ms
- F3SJ-A0380N20 F3SJ-A0500N25 F3SJ-A0620N30 F3SJ-A1220N55 25 beams 11ms 44ms
F3SJ-A0245N14 F3SJ-A0395N20 F3SJ-A0520N25 F3SJ-A0645N30 F3SJ-A1270N55 26 beams 11ms 44ms
F3SJ-A0254N14 F3SJ-A0410N20 F3SJ-A0540N25 F3SJ-A0670N30 F3SJ-A1320N55 27 beams 11ms 44ms
F3SJ-A0263N14 F3SJ-A0425N20 F3SJ-A0560N25 F3SJ-A0695N30 F3SJ-A1370N55 28 beams 11ms 44ms
F3SJ-A0272N14 F3SJ-A0440N20 F3SJ-A0580N25 F3SJ-A0720N30 F3SJ-A1420N55 29 beams 11ms 44ms
F3SJ-A0281N14 F3SJ-A0455N20 F3SJ-A0600N25 F3SJ-A0745N30 F3SJ-A1470N55 30 beams 12ms 48ms
F3SJ-A0290N14 F3SJ-A0470N20 F3SJ-A0620N25 F3SJ-A0770N30 F3SJ-A1520N55 31 beams 12ms 48ms
F3SJ-A0299N14 F3SJ-A0485N20 F3SJ-A0640N25 F3SJ-A0795N30 F3SJ-A1570N55 32 beams 12ms 48ms
F3SJ-A0308N14 F3SJ-A0500N20 F3SJ-A0660N25 F3SJ-A0820N30 F3SJ-A1620N55 33 beams 12ms 48ms
F3SJ-A0317N14 F3SJ-A0515N20 F3SJ-A0680N25 F3SJ-A0845N30 F3SJ-A1670N55 34 beams 12ms 48ms
F3SJ-A0326N14 F3SJ-A0530N20 F3SJ-A0700N25 F3SJ-A0870N30 F3SJ-A1720N55 35 beams 12ms 48ms
F3SJ-A0335N14 F3SJ-A0545N20 F3SJ-A0720N25 F3SJ-A0895N30 F3SJ-A1770N55 36 beams 12ms 48ms
F3SJ-A0344N14 F3SJ-A0560N20 F3SJ-A0740N25 F3SJ-A0920N30 F3SJ-A1820N55 37 beams 12ms 48ms
F3SJ-A0353N14 F3SJ-A0575N20 F3SJ-A0760N25 F3SJ-A0945N30 F3SJ-A1870N55 38 beams 12ms 48ms
F3SJ-A0362N14 F3SJ-A0590N20 F3SJ-A0780N25 F3SJ-A0970N30 F3SJ-A1920N55 39 beams 12ms 48ms
F3SJ-A0371N14 F3SJ-A0605N20 F3SJ-A0800N25 F3SJ-A0995N30 F3SJ-A1970N55 40 beams 12ms 48ms
F3SJ-A0380N14 F3SJ-A0620N20 F3SJ-A0820N25 F3SJ-A1020N30 F3SJ-A2020N55 41 beams 12ms 48ms
F3SJ-A0389N14 F3SJ-A0635N20 F3SJ-A0840N25 F3SJ-A1045N30 F3SJ-A2070N55 42 beams 12ms 48ms
F3SJ-A0398N14 F3SJ-A0650N20 F3SJ-A0860N25 F3SJ-A1070N30 F3SJ-A2120N55 43 beams 13ms 52ms
F3SJ-A0407N14 F3SJ-A0665N20 F3SJ-A0880N25 F3SJ-A1095N30 F3SJ-A2170N55 44 beams 13ms 52ms
F3SJ-A0416N14 F3SJ-A0680N20 F3SJ-A0900N25 F3SJ-A1120N30 F3SJ-A2220N55 45 beams 13ms 52ms
F3SJ-A0425N14 F3SJ-A0695N20 F3SJ-A0920N25 F3SJ-A1145N30 F3SJ-A2270N55 46 beams 13ms 52ms
F3SJ-A0434N14 F3SJ-A0710N20 F3SJ-A0940N25 F3SJ-A1170N30 F3SJ-A2320N55 47 beams 13ms 52ms
F3SJ-A0443N14 F3SJ-A0725N20 F3SJ-A0960N25 F3SJ-A1195N30 F3SJ-A2370N55 48 beams 13ms 52ms
F3SJ-A0452N14 F3SJ-A0740N20 F3SJ-A0980N25 F3SJ-A1220N30 F3SJ-A2420N55 49 beams 13ms 52ms

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
