Chapter1 Ratings
F3SJ-A
User’s Manual
Overview and Specifications
Material Casing (including metal parts on both ends): Aluminum, zinc die-cast
Cap: ABS resin
Optical cover: PMMA resin (acrylic)
Cable: Oil resistant PVC
Weight (packaged) - F3SJ-AN14
Weight (g)=(protective height) x 1.7+ α
- F3SJ-AN20/F3SJ-AN25/F3SJ-AN30
Weight (g)=(protective height) x 1.5+ α
- F3SJ-AN55
Weight (g)=(protective height) x 1.4+ α
The values for α are as follows:
When protective height is between 245 and 596mm, α=1100
When protective height is between 600 and 1130mm, α=1500
When protective height is between 1136 and 1658mm, α=2000
When protective height is between 1660 and 2180mm, α=2400
When protective height is between 2195 and 2500mm, α=2600
Accessories Instruction sheet, top and bottom mounting brackets, intermediate mounting brackets *, error
mode label, user’s manual (CD-ROM)
* The number of intermediate mounting brackets depends on the total length of the F3SJ.
- F3SJ total length is from 600 to 1,130mm: 1 set for each the emitter and receiver is included
- F3SJ total length is from 1136 to 1,658mm: 2 sets for each the emitter and receiver are
included
- F3SJ total length is from 1660 to 2,180mm: 3 sets for each the emitter and receiver are
included
- F3SJ total length is from 2195 to 2500mm: 4 sets for each the emitter and receiver are
included
Applicable standards IEC61496-1, EN61496-1, UL61496-1 Type 4ESPE (Electro-Sensitive Protective Equipment)
IEC61496-2, CLC/TS 61496-2, UL61496-2 Type 4AOPD (Active Opto-electronic Protective
Devices)
IEC61508, EN61508 SIL3, EN ISO 13849-1:2008 (Category 4, PL e), ISO 13849-1:2006
(Category 4, PL e)
Safety-related characteristic data
(EN 61508:2010)
See http://www.fa.omron.co.jp/safety_6en/
F3SJ-A
N14
F3SJ-A
N20
F3SJ-A
N25
F3SJ-A
N30
F3SJ-A
N55
