147
F3SJ-A
User’s Manual
Chapter4 Dimensions
Wiring/Installation
E
Setting Tool
F39-GWUM PC Tool for F3SJ
F39-MC21 Setting Console
67.9
35.8
17.8
3.6
0.7
(8)
(16)(12)
(4.5)
(625.7)
(46)
(11.8)
Insulated vinyl round cord dia. 4.6
Standard length 0.5m
22
52.8
136
50
Left Key
Cancel Key
Communication Jack
Connection Indicator
Function Selection Indicato
r
Channel Indicator
Channel Keys
Mode Indicator
Up Key
Right Key
Down Key
Enter Key
