Omron F3SJ Series User Manual

91
F3SJ-A
User’s Manual
Chapter3 Setting Adjusted to Application
What can be done by the setting tool
E
 Override Function
 Overview
Configures override function.
The override function disables safety functions of the device. You must ensure safety
using other measures during this function is enabled.
All external indicators that indicate state of override function must be installed where
workers can see them from all the operating positions.
Install the switch that activates the override and that uses hold-to-run device, such as
spring-return key switch, in a location that provides a clear view of the entire hazardous
zone and where it cannot be activated from within the hazardous zone. Make sure that
nobody is in the hazardous zone before activating the override function.
Override time must be properly configured for its application by a sufficiently trained and
qualified person.
 Example
•To extend override continuance time
 Functional Description
• Override Function
The setting tool can disable override function. (Enabled for factory shipment)
Override Function p.52
• Override Time Limit
Override continuance time at the function’s activation can be changed. (60s for factory shipment)
 Setting Change
Configure in a bulk in case of a series connection. (to be written into the primary sensor only)
If override function is enabled, we recommend either output mode of external indicator output 1, 2, or auxiliary output
1 should be configured as shown below.
- Override information
- Muting/override information
 Setting Zone Adjacent Conditions
If any two functions of muting, fixed blanking, floating blanking, or warning zone functions are used at
the same time, the setting zones have limitations.
This section describes the limitations for following points:
1. Zone adjacent condition: If zones for multiple functions are configured adjacently
2. Zone overlap condition: If zones for multiple functions are configured as overlapped
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Override Function Enabled Enable/disable – 
Override Time Limit 60s 1s to 600s (by 1s) 

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
