90
Chapter3 Setting Adjusted to Application
F3SJ-A
User’s Manual
What can be done by the setting tool
 Setting Change
Setting items vary according to the mode.
Muting zone setting: Configure for each CH in case of a series connection.
Other than the above: Configure in a bulk in case of a series connection. (to be written into the primary
sensor only)
Standard muting mode
Exit only muting mode (PC tool for F3SJ only)
Position detection muting mode (PC tool for F3SJ only)
If muting function is enabled, either output mode of external indicator output 1, 2, or auxiliary output 1 must be
configured as shown below.
- Muting information
- Muting/override information
 Limitation for Combination with Other Functions
You can use this function in combination with fixed blanking, floating blanking, and warning zone
functions at the same time with the PC tool for F3SJ. Note that there is a limitation for setting with
zones.
The setting console can be combined with fixed blanking function.
For details, see Setting Zone Adjacent Conditions p.91 .
Setting Zone Adjacent Conditions p.91
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Muting Zone Setting All beams 1 to all beams 
T1min: Muting input time limit
(minimum value)
0.03s 0.03s, 0.1s to 3.9s (by 0.1s)
– 
T1max: Muting input time limit
(maximum value)
3s 0.2s to 4s (by 0.1s)
– 
T2: Muting time limit 60s 1s to 600s (by 1s) or infinite 
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Muting Zone Setting All beams 1 to all beams – 
T1min: Muting input time limit
(minimum value)
0.03s 0.03s, 0.1s to 3.9s (by 0.1s)
– 
T1max: Muting input time limit
(maximum value)
3s 0.2s to 4s (by 0.1s)
– 
T2: Muting time limit 60s 1s to 600s (by 1s) or infinite – 
T5: Exit only muting delay time 4s 0.1s to 4s (by 0.1s) – 
Function Initial Setting Available Setup Item Setting Console PC Tool For F3SJ
Muting Zone Setting All beams 1 to all beams – 
T1min: Muting input time limit
(maximum value)
3s 0.1s to 4s (by 0.1s)
– 
T2: Muting time limit 60s 1s to 600s (by 1s) or infinite – 

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
