159
F3SJ-A
User’s Manual
Chapter4 Wiring
Wiring/Installation
E
Wiring Procedure
1. Connect an emitter cable (F39-JC-L/F39-JD-L, grey, sold separately) to the emitter's
connection cable (grey).
2. Connect a receiver cable (F39-JC-D/F39-JD-D, black, sold separately) to the receiver's
connection cable (black).
3. Connect the +24V line of the power supply directly to the protective earth (PE).
To ensure proper wiring, check that the color of the cable matches the color of the connector's resin cover (emitter: grey,
receiver: black). Failure to do so may result in damage to the F3SJ. Incorrect wiring can be prevented by matching the
colors.
Cable with Connector on One End (F39-JDA*, sold separately)
Internal wiring diagram (F39-JDA-L, F39-JDA-D)
Set model name For emitter For receiver L (mm) *
F39-JD3A F39-JD3A-L Grey cable F39-JD3A-D Black cable 3000
F39-JD7A F39-JD7A-L F39-JD7A-D 7000
F39-JD10A F39-JD10A-L F39-JD10A-D 10000
F39-JD15A F39-JD15A-L F39-JD15A-D 15000
F39-JD20A F39-JD20A-L F39-JD20A-D 20000
dia.15
39.5
L
8-wire (4-pair) (Cross section of conductor: 0.3mm
2
/insulator diameter: dia. 1.15mm) *
(Unit: mm)
M12 IP67 Connector
Insulated vinyl round cable dia. 6.6, shielded
1
2
3
4
5
6
7
8
+24V DC
0V
+24V DC
0V
Emitter
Receiver
Female
White
Brown
Black*
Grey
Pink
Blue
Red
Shield
Shield
Yellow
White
Brown
Black*
Grey
Pink
Blue
Red
Yellow
Twisted pair wires are white and red, brown and blue, black* and yellow, and grey and pink.
* The size and the number of wires of the single-ended cable F39-JCA are the same as those of F39-JDA.
Green for pin #3 wiring color of the single-ended cable F39-JCA.
Interlock selection input
Test input
Reset input
Auxiliary output 2
External device
monitoring input
Control output 1
Safety output 2
Auxiliary output 1
Communication line (+)
Communication line (-)
Communication line (+)
Communication line (-)
5
8
4
3
2
1
7
6
Connected to power cable, double-ended
connector cable, and reduced wiring
connector
To Next Page
