Omron F3SJ Series User Manual

18
Chapter1 Ratings
F3SJ-A
User’s Manual
Overview and Specifications
F3SJ-A0461N14 F3SJ-A0755N20 F3SJ-A1000N25 F3SJ-A1245N30 F3SJ-A2470N55 50 beams 13ms 52ms
F3SJ-A0470N14 F3SJ-A0770N20 F3SJ-A1020N25 F3SJ-A1270N30 - 51 beams 13ms 52ms
F3SJ-A0479N14 F3SJ-A0785N20 F3SJ-A1040N25 F3SJ-A1295N30 - 52 beams 13ms 52ms
F3SJ-A0488N14 F3SJ-A0800N20 F3SJ-A1060N25 F3SJ-A1320N30 - 53 beams 13ms 52ms
F3SJ-A0497N14 F3SJ-A0815N20 F3SJ-A1080N25 F3SJ-A1345N30 - 54 beams 13ms 52ms
F3SJ-A0506N14 F3SJ-A0830N20 F3SJ-A1100N25 F3SJ-A1370N30 - 55 beams 13ms 52ms
F3SJ-A0515N14 F3SJ-A0845N20 F3SJ-A1120N25 F3SJ-A1395N30 - 56 beams 14ms 56ms
F3SJ-A0524N14 F3SJ-A0860N20 F3SJ-A1140N25 F3SJ-A1420N30 - 57 beams 14ms 56ms
F3SJ-A0533N14 F3SJ-A0875N20 F3SJ-A1160N25 F3SJ-A1445N30 - 58 beams 14ms 56ms
F3SJ-A0542N14 F3SJ-A0890N20 F3SJ-A1180N25 F3SJ-A1470N30 - 59 beams 14ms 56ms
F3SJ-A0551N14 F3SJ-A0905N20 F3SJ-A1200N25 F3SJ-A1495N30 - 60 beams 14ms 56ms
F3SJ-A0560N14 F3SJ-A0920N20 F3SJ-A1220N25 F3SJ-A1520N30 - 61 beams 14ms 56ms
F3SJ-A0569N14 F3SJ-A0935N20 F3SJ-A1240N25 F3SJ-A1545N30 - 62 beams 14ms 56ms
F3SJ-A0578N14 F3SJ-A0950N20 F3SJ-A1260N25 F3SJ-A1570N30 - 63 beams 14ms 56ms
F3SJ-A0587N14 F3SJ-A0965N20 F3SJ-A1280N25 F3SJ-A1595N30 - 64 beams 14ms 56ms
F3SJ-A0596N14 F3SJ-A0980N20 F3SJ-A1300N25 F3SJ-A1620N30 - 65 beams 14ms 56ms
F3SJ-A0605N14 F3SJ-A0995N20 F3SJ-A1320N25 F3SJ-A1645N30 - 66 beams 14ms 56ms
F3SJ-A0614N14 F3SJ-A1010N20 F3SJ-A1340N25 F3SJ-A1670N30 - 67 beams 14ms 56ms
F3SJ-A0623N14 F3SJ-A1025N20 F3SJ-A1360N25 F3SJ-A1695N30 - 68 beams 15ms 60ms
F3SJ-A0632N14 F3SJ-A1040N20 F3SJ-A1380N25 F3SJ-A1720N30 - 69 beams 15ms 60ms
F3SJ-A0641N14 F3SJ-A1055N20 F3SJ-A1400N25 F3SJ-A1745N30 - 70 beams 15ms 60ms
F3SJ-A0650N14 F3SJ-A1070N20 F3SJ-A1420N25 F3SJ-A1770N30 - 71 beams 15ms 60ms
F3SJ-A0659N14 F3SJ-A1085N20 F3SJ-A1440N25 F3SJ-A1795N30 - 72 beams 15ms 60ms
F3SJ-A0668N14 F3SJ-A1100N20 F3SJ-A1460N25 F3SJ-A1820N30 - 73 beams 15ms 60ms
F3SJ-A0677N14 F3SJ-A1115N20 F3SJ-A1480N25 F3SJ-A1845N30 - 74 beams 15ms 60ms
F3SJ-A0686N14 F3SJ-A1130N20 F3SJ-A1500N25 F3SJ-A1870N30 - 75 beams 15ms 60ms
F3SJ-A0695N14 F3SJ-A1145N20 F3SJ-A1520N25 F3SJ-A1895N30 - 76 beams 15ms 60ms
F3SJ-A0704N14 F3SJ-A1160N20 F3SJ-A1540N25 F3SJ-A1920N30 - 77 beams 15ms 60ms
F3SJ-A0713N14 F3SJ-A1175N20 F3SJ-A1560N25 F3SJ-A1945N30 - 78 beams 15ms 60ms
F3SJ-A0722N14 F3SJ-A1190N20 F3SJ-A1580N25 F3SJ-A1970N30 - 79 beams 15ms 60ms
F3SJ-A0731N14 F3SJ-A1205N20 F3SJ-A1600N25 F3SJ-A1995N30 - 80 beams 15ms 60ms
F3SJ-A0740N14 F3SJ-A1220N20 F3SJ-A1620N25 F3SJ-A2020N30 - 81 beams 17.5ms 70ms
F3SJ-A0749N14 F3SJ-A1235N20 F3SJ-A1640N25 F3SJ-A2045N30 - 82 beams 17.5ms 70ms
F3SJ-A0758N14 F3SJ-A1250N20 F3SJ-A1660N25 F3SJ-A2070N30 - 83 beams 17.5ms 70ms
F3SJ-A0767N14 F3SJ-A1265N20 F3SJ-A1680N25 F3SJ-A2095N30 - 84 beams 17.5ms 70ms
F3SJ-A0776N14 F3SJ-A1280N20 F3SJ-A1700N25 F3SJ-A2120N30 - 85 beams 17.5ms 70ms
F3SJ-A0785N14 F3SJ-A1295N20 F3SJ-A1720N25 F3SJ-A2145N30 - 86 beams 17.5ms 70ms
F3SJ-A0794N14 F3SJ-A1310N20 F3SJ-A1740N25 F3SJ-A2170N30 - 87 beams 17.5ms 70ms
F3SJ-A0803N14 F3SJ-A1325N20 F3SJ-A1760N25 F3SJ-A2195N30 - 88 beams 17.5ms 70ms
F3SJ-A0812N14 F3SJ-A1340N20 F3SJ-A1780N25 F3SJ-A2220N30 - 89 beams 17.5ms 70ms
F3SJ-A0821N14 F3SJ-A1355N20 F3SJ-A1800N25 F3SJ-A2245N30 - 90 beams 17.5ms 70ms
F3SJ-A0830N14 F3SJ-A1370N20 F3SJ-A1820N25 F3SJ-A2270N30 - 91 beams 17.5ms 70ms
F3SJ-A0839N14 F3SJ-A1385N20 F3SJ-A1840N25 F3SJ-A2295N30 - 92 beams 17.5ms 70ms
F3SJ-A0848N14 F3SJ-A1400N20 F3SJ-A1860N25 F3SJ-A2320N30 - 93 beams 17.5ms 70ms
F3SJ-A0857N14 F3SJ-A1415N20 F3SJ-A1880N25 F3SJ-A2345N30 - 94 beams 17.5ms 70ms
F3SJ-A0866N14 F3SJ-A1430N20 F3SJ-A1900N25 F3SJ-A2370N30 - 95 beams 17.5ms 70ms
F3SJ-A0875N14 F3SJ-A1445N20 F3SJ-A1920N25 F3SJ-A2395N30 - 96 beams 17.5ms 70ms
F3SJ-A
N14
F3SJ-A
N20
F3SJ-A
N25
F3SJ-A
N30
F3SJ-A
N55
Number of
beams
Response
time
(ON to OFF)
Response
time
(OFF to ON)

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
