Omron F3SJ Series User Manual

19
F3SJ-A
User’s Manual
Chapter1 Ratings
Overview and Specifications
E
F3SJ-A0884N14 F3SJ-A1460N20 F3SJ-A1940N25 F3SJ-A2420N30 - 97 beams 17.5ms 70ms
F3SJ-A0893N14 F3SJ-A1475N20 F3SJ-A1960N25 F3SJ-A2445N30 - 98 beams 17.5ms 70ms
F3SJ-A0902N14 F3SJ-A1490N20 F3SJ-A1980N25 F3SJ-A2470N30 - 99 beams 17.5ms 70ms
F3SJ-A0911N14 F3SJ-A1505N20 F3SJ-A2000N25 F3SJ-A2495N30 - 100 beams 17.5ms 70ms
F3SJ-A0920N14 F3SJ-A1520N20 F3SJ-A2020N25 - - 101 beams 17.5ms 70ms
F3SJ-A0929N14 F3SJ-A1535N20 F3SJ-A2040N25 - - 102 beams 17.5ms 70ms
F3SJ-A0938N14 F3SJ-A1550N20 F3SJ-A2060N25 - - 103 beams 17.5ms 70ms
F3SJ-A0947N14 F3SJ-A1565N20 F3SJ-A2080N25 - - 104 beams 17.5ms 70ms
F3SJ-A0956N14 F3SJ-A1580N20 F3SJ-A2100N25 - - 105 beams 17.5ms 70ms
F3SJ-A0965N14 F3SJ-A1595N20 F3SJ-A2120N25 - - 106 beams 17.5ms 70ms
F3SJ-A0974N14 F3SJ-A1610N20 F3SJ-A2140N25 - - 107 beams 17.5ms 70ms
F3SJ-A0983N14 F3SJ-A1625N20 F3SJ-A2160N25 - - 108 beams 17.5ms 70ms
F3SJ-A0992N14 F3SJ-A1640N20 F3SJ-A2180N25 - - 109 beams 17.5ms 70ms
F3SJ-A1001N14 F3SJ-A1655N20 F3SJ-A2200N25 - - 110 beams 17.5ms 70ms
F3SJ-A1010N14 F3SJ-A1670N20 F3SJ-A2220N25 - - 111 beams 17.5ms 70ms
F3SJ-A1019N14 F3SJ-A1685N20 F3SJ-A2240N25 - - 112 beams 17.5ms 70ms
F3SJ-A1028N14 F3SJ-A1700N20 F3SJ-A2260N25 - - 113 beams 20.0ms 80ms
F3SJ-A1037N14 F3SJ-A1715N20 F3SJ-A2280N25 - - 114 beams 20.0ms 80ms
F3SJ-A1046N14 F3SJ-A1730N20 F3SJ-A2300N25 - - 115 beams 20.0ms 80ms
F3SJ-A1055N14 F3SJ-A1745N20 F3SJ-A2320N25 - - 116 beams 20.0ms 80ms
F3SJ-A1064N14 F3SJ-A1760N20 F3SJ-A2340N25 - - 117 beams 20.0ms 80ms
F3SJ-A1073N14 F3SJ-A1775N20 F3SJ-A2360N25 - - 118 beams 20.0ms 80ms
F3SJ-A1082N14 F3SJ-A1790N20 F3SJ-A2380N25 - - 119 beams 20.0ms 80ms
F3SJ-A1091N14 F3SJ-A1805N20 F3SJ-A2400N25 - - 120 beams 20.0ms 80ms
F3SJ-A1100N14 F3SJ-A1820N20 F3SJ-A2420N25 - - 121 beams 20.0ms 80ms
F3SJ-A1109N14 F3SJ-A1835N20 F3SJ-A2440N25 - - 122 beams 20.0ms 80ms
F3SJ-A1118N14 F3SJ-A1850N20 F3SJ-A2460N25 - - 123 beams 20.0ms 80ms
F3SJ-A1127N14 F3SJ-A1865N20 F3SJ-A2480N25 - - 124 beams 20.0ms 80ms
F3SJ-A1136N14 F3SJ-A1880N20 F3SJ-A2500N25 - - 125 beams 20.0ms 80ms
F3SJ-A1145N14 F3SJ-A1895N20 - - - 126 beams 20.0ms 80ms
F3SJ-A1154N14 F3SJ-A1910N20 - - - 127 beams 20.0ms 80ms
F3SJ-A1163N14 F3SJ-A1925N20 - - - 128 beams 20.0ms 80ms
F3SJ-A1172N14 F3SJ-A1940N20 - - - 129 beams 20.0ms 80ms
F3SJ-A1181N14 F3SJ-A1955N20 - - - 130 beams 20.0ms 80ms
F3SJ-A1190N14 F3SJ-A1970N20 - - - 131 beams 20.0ms 80ms
F3SJ-A1199N14 F3SJ-A1985N20 - - - 132 beams 20.0ms 80ms
F3SJ-A1208N14 F3SJ-A2000N20 - - - 133 beams 20.0ms 80ms
F3SJ-A1217N14 F3SJ-A2015N20 - - - 134 beams 20.0ms 80ms
F3SJ-A1226N14 F3SJ-A2030N20 - - - 135 beams 20.0ms 80ms
F3SJ-A1235N14 F3SJ-A2045N20 - - - 136 beams 20.0ms 80ms
F3SJ-A1244N14 F3SJ-A2060N20 - - - 137 beams 20.0ms 80ms
F3SJ-A1253N14 F3SJ-A2075N20 - - - 138 beams 20.0ms 80ms
F3SJ-A1262N14 F3SJ-A2090N20 - - - 139 beams 20.0ms 80ms
F3SJ-A1271N14 F3SJ-A2105N20 - - - 140 beams 20.0ms 80ms
F3SJ-A1280N14 F3SJ-A2120N20 - - - 141 beams 20.0ms 80ms
F3SJ-A1289N14 F3SJ-A2135N20 - - - 142 beams 20.0ms 80ms
F3SJ-A1298N14 F3SJ-A2150N20 - - - 143 beams 20.0ms 80ms
F3SJ-A
N14
F3SJ-A
N20
F3SJ-A
N25
F3SJ-A
N30
F3SJ-A
N55
Number of
beams
Response
time
(ON to OFF)
Response
time
(OFF to ON)

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
