Omron F3SJ Series User Manual

20
Chapter1 Ratings
F3SJ-A
User’s Manual
Overview and Specifications
F3SJ-A1307N14 F3SJ-A2165N20 - - - 144 beams 20.0ms 80ms
F3SJ-A1316N14 F3SJ-A2180N20 - - - 145 beams 22.5ms 90ms
F3SJ-A1325N14 F3SJ-A2195N20 - - - 146 beams 22.5ms 90ms
F3SJ-A1334N14 F3SJ-A2210N20 - - - 147 beams 22.5ms 90ms
F3SJ-A1343N14 F3SJ-A2225N20 - - - 148 beams 22.5ms 90ms
F3SJ-A1352N14 F3SJ-A2240N20 - - - 149 beams 22.5ms 90ms
F3SJ-A1361N14 F3SJ-A2255N20 - - - 150 beams 22.5ms 90ms
F3SJ-A1370N14 F3SJ-A2270N20 - - - 151 beams 22.5ms 90ms
F3SJ-A1379N14 F3SJ-A2285N20 - - - 152 beams 22.5ms 90ms
F3SJ-A1388N14 F3SJ-A2300N20 - - - 153 beams 22.5ms 90ms
F3SJ-A1397N14 F3SJ-A2315N20 - - - 154 beams 22.5ms 90ms
F3SJ-A1406N14 F3SJ-A2330N20 - - - 155 beams 22.5ms 90ms
F3SJ-A1415N14 F3SJ-A2345N20 - - - 156 beams 22.5ms 90ms
F3SJ-A1424N14 F3SJ-A2360N20 - - - 157 beams 22.5ms 90ms
F3SJ-A1433N14 F3SJ-A2375N20 - - - 158 beams 22.5ms 90ms
F3SJ-A1442N14 F3SJ-A2390N20 - - - 159 beams 22.5ms 90ms
F3SJ-A1451N14 F3SJ-A2405N20 - - - 160 beams 22.5ms 90ms
F3SJ-A1460N14 F3SJ-A2420N20 - - - 161 beams 22.5ms 90ms
F3SJ-A1469N14 F3SJ-A2435N20 - - - 162 beams 22.5ms 90ms
F3SJ-A1478N14 F3SJ-A2450N20 - - - 163 beams 22.5ms 90ms
F3SJ-A1487N14 F3SJ-A2465N20 - - - 164 beams 22.5ms 90ms
F3SJ-A1496N14 F3SJ-A2480N20 - - - 165 beams 22.5ms 90ms
F3SJ-A1505N14 F3SJ-A2495N20 - - - 166 beams 22.5ms 90ms
F3SJ-A1514N14 - - - - 167 beams 22.5ms 90ms
F3SJ-A1523N14 - - - - 168 beams 22.5ms 90ms
F3SJ-A1532N14 - - - - 169 beams 22.5ms 90ms
F3SJ-A1541N14 - - - - 170 beams 22.5ms 90ms
F3SJ-A1550N14 - - - - 171 beams 22.5ms 90ms
F3SJ-A1559N14 - - - - 172 beams 22.5ms 90ms
F3SJ-A1568N14 - - - - 173 beams 22.5ms 90ms
F3SJ-A1577N14 - - - - 174 beams 22.5ms 90ms
F3SJ-A1586N14 - - - - 175 beams 22.5ms 90ms
F3SJ-A1595N14 - - - - 176 beams 22.5ms 90ms
F3SJ-A1604N14 - - - - 177 beams 25.0ms 100ms
F3SJ-A1613N14 - - - - 178 beams 25.0ms 100ms
F3SJ-A1622N14 - - - - 179 beams 25.0ms 100ms
F3SJ-A1631N14 - - - - 180 beams 25.0ms 100ms
F3SJ-A1640N14 - - - - 181 beams 25.0ms 100ms
F3SJ-A1649N14 - - - - 182 beams 25.0ms 100ms
F3SJ-A1658N14 - - - - 183 beams 25.0ms 100ms
F3SJ-A1667N14 - - - - 184 beams 25.0ms 100ms
F3SJ-A1676N14 - - - - 185 beams 25.0ms 100ms
F3SJ-A1685N14 - - - - 186 beams 25.0ms 100ms
F3SJ-A1694N14 - - - - 187 beams 25.0ms 100ms
F3SJ-A1703N14 - - - - 188 beams 25.0ms 100ms
F3SJ-A1712N14 - - - - 189 beams 25.0ms 100ms
F3SJ-A1721N14 - - - - 190 beams 25.0ms 100ms
F3SJ-A
N14
F3SJ-A
N20
F3SJ-A
N25
F3SJ-A
N30
F3SJ-A
N55
Number of
beams
Response
time
(ON to OFF)
Response
time
(OFF to ON)

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
