Omron F3SJ Series User Manual

128
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
Dimensions A to E
Dimension E
*1. Use E = 530 or less when none of the E values shown above are used.
 Dimensions of Standard Brackets (top/bottom mounting brackets)
AC + 74
B C + 46.5
C 4-digit number of the model name (protective height)
DC - 20
E Depends on the protective height. See the table below.
Protective height
Number of intermediate
mounting brackets
E*1
0245 to 0596 0 -
0600 to 1130 1 B/2
1136 to 1658 2 B/3
1660 to 2180 3 B/4
2195 to 2500 4 B/5
16
2
30
19.6
21
10
9
19.6
8
18
11
5.5
36.5
16.5
14.5
13.5
A-A
A
A
11.5
21
30
10
2-M3
Through holes
(Unit: mm)
Material: Stainless steel
Material: Stainless steel
Material: Brass
5.6
5.5
dia. 9
dia. 6.5
2-dia. 3.5

Omron F3SJ Series Specifications

General

Type	Safety Light Curtain
Safety Category	Category 4
Protection Rating	IP67
SIL	SIL3
Operating Temperature	-10°C to +55°C
Detection Method	Infrared
Resolution	14 mm
IP Rating	IP67
Certification	CE
Power Supply Voltage	24 VDC ±10%
