Operation and Test Run
3 - 25
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Item
Description
Reference
Parameter Setting
Set the parameters required for the test run.
Section 5,
5-3, 5-4
No-load Run
Run the motor with no-load via the Digital Operator.
Section 3,
3-1
Load Run
Run the motor via Digital Operator, with the mechanical system con-
nected.
Section 3,
3-1
Operation
Basic settings (operation with the basic settings required to operate
and stop the inverter.)
Section 5
Vector control (operation with the vector control and other functions.)
Section 6
3
3-3 Flow of Test Run
3-2-3 Precautions for Using CX-Drive
Installation
Install the inverter according to the installation conditions.
Section 2,
2-1
Wiring and con-
nections
Connect the inverter to the power supply and peripheral equipment.
Section 2,
2-10
Power-on
Check the points mentioned in the next page before turning on the
power supply.
Section 3,
3-4
Display Status
Checks
Check that there is no error in the inverter.
Section
10
Parameter Initial-
ization
Initialize the inverter parameters.
Section 5,
5-1
